SY265C
HIGH-TECH SOLUTIONS REDEFINED

INDUSTRY LEADING 5-YEAR WARRANTY

The SY265C excavator brings new meaning to the term ‘flexibility“. It is ideal for carrying out a wide range of tasks whether in road construction, materials handling or demolition work. Its drive and hydraulics leave nothing to be desired and combine power, reliability and precision for impressive productivity. Just as you would expect from an excavator within this category.



– Stage V CUMMINS engine and finely tuned Kawasaki hydraulic system
– Comfortable ROPS/FOPS certified operators cab
– 5 year warranty for complete peace of mind

  • RATED POWER
    145 kW / 2000 rpm
  • OPERATING WEIGHT
    27,000 kg
  • DIG DEPTH
    6,705 mm
Benefits & Features

PERFORMANCE

The SANY SY265C is multifaceted when it comes to cost-effectiveness. Its sensationally low fuel consumption together with the sophisticated maintenance concept is the key to impressively low operating costs.



+ Heavy-duty undercarriage and solid boom provide an exemplary level of stability

+ Stage V CUMMINS engine and smart hydraulic control system to maximise on fuel economy

+ Hammer, bi-directional and rotate pipework with proportional controls enabling maximum versatility whatever the application

+ 100% steel bodywork for maximum protection and reduced cost of ownership



SAFETY

The SY265C provides optimal jobsite safety thanks to its combination of safety features.



+ ROPS/FOPS certified cab for safe operation

+ Rear and side view camera for panoramic visibility

+ Travel alarm, green seat belt and rotating warning beacon to increase visibility, attract attention and ensure safety

+ LED work lights for maximum visibility in low light conditions



OPERATOR COMFORT

The SY265C provides the kind of comfort that operators appreciate!



+ Ergonomic and fully adjustable, heated operator’s seat

+ Clear instrumentation and large high resolution colour display

+ Adjustable ventilation, heating and automatic climate control system

+ Integrated cooling box and large amount of storage space

+ Radio, speaker and USB port



SERVICE

+ Easy access to all maintenance points

+ Low maintenance requirements and longer service intervals

+ Ergonomic handrails and anti-slip tread surfaces allow safe access to the maintenance platform



SECURITY

+ Registered and protected with the CESAR Datatag Scheme (the premier initiative against equipment theft) and CESAR ECV for quick and easy verification of emissions category



WARRANTY

+ 5-year/5000 hour warranty as standard for complete peace of mind (Terms and Conditions apply)

Specifications
DIMENSIONS
Transport length 10,290 mm
Transport width 3,290 mm
Transport height 3,225 mm
Upper structure carriage 3,045 mm
Height over cabin/ROPS 3,040 mm
Height of Boom – transport 3,365 mm
Overall length of crawler 4,636 mm
Track gauge 2,590 mm
Track height 945 mm
Track pads width Standard 700 mm. Optional 600 mm or 800 mm
Minimum ground clearance 470 mm
Counterweight clearance 1,045 mm
Engine cover height 2,640 mm
Tail swing radius 3,105 mm
Centre distance of tumblers 3,833 mm
Ground pressure 39.3 KPa

WEIGHT
Operating weight 27,000 kg

ENGINE
Model Cummins QSB 6.7 – 6 cylinder
Rated power 145 kw
Max. Torque 1472 Nm
Displacement 6.7 l
Exhaust emissions Stage V
Batteries 24 v

HYDRAULIC SYSTEM
Max. Oil flow 2x 260 l/min

RELIEF VALVE SETTING
Implement circuit 34.3 MPa
Power boost 37.3 MPa
Swing circuit 29 MPa
Travel circuit 34.3 MPa
Pilot pressure 3.9 MPa

SERVICE REFILL CAPACITIES
Fuel tank 465 l
Engine coolant 40 l
Engine oil 27 l
Drive (per side) 7.8 l
Hydraulic oil tank 275 l
AdBlue 38 l

PERFORMANCE
Swing speed 10.6 rpm
Travel speed (Low/High) 3.7/5.5 km/h
Max. travel force 227 kN
Gradeability 70%*(35°)
Bucket digging force ISO 187 kN
Arm digging force ISO 130 kN
Boom length 5,900 mm
Arm length 2,950 mm
Bottom rollers 9
Top rollers 2

WORKING RANGE
Max. digging reach 10,225 mm
Max. digging depth 6,705 mm
Max. digging Height 9,750 mm
Max. dumping height 6,715 mm
Max. vertical digging depth 5,675 mm
Overall height over arm by Min . swing radius 8,020 mm
Min. swing radius 3,880 mm
